 Topic: PCM Starter QuestionPosted: December-09-2008 at 12:31pm |
|
I have a 2004 ZR6 that has the starter located in the typical GM location which is on the lower Stb side of the engine.
The bellhousing has a provision for a top mounted starter. Has anyone converted to the top mounted starter and if so does it require a different flywheel? Any information and part numbers will be appreciated. Gary |
|
 |
|
|
79nautique
Grand Poobah
Joined: January-27-2004 Location: United States Status: Offline Points: 7872 |
Post Options
Thanks(0)
Quote Reply
Posted: December-09-2008 at 12:55pm |
|
why would you want to change it from is present location?
|
|
|
|
|
GaryM
Newbie
Joined: March-13-2008 Location: Chesapeaks Bay Status: Offline Points: 24 |
Post Options
Thanks(0)
Quote Reply
Posted: December-09-2008 at 1:01pm |
|
Two reasons. This is a 23 Fish Nautique. It is all but impossible to remove the starter with the engine in the boat as it sits very close the the bilge. And for that same reason it is very easy to get the starter wet with bilge water. I have the engine out of the boat so now is the time to make the change.
|
|
|
|
|
79nautique
Grand Poobah
Joined: January-27-2004 Location: United States Status: Offline Points: 7872 |
Post Options
Thanks(0)
Quote Reply
Posted: December-09-2008 at 1:09pm |
|
if the motor is reverse rotation then all you need to do is get a standard rotation unit and mount it in the top spot assuming that the unit will also be mounted on the other side of the flywheel.
the unit should be sealed and if water gets into the bilge it should not effect the starter. |
|
|
|
|
TRBenj
Grand Poobah
Joined: June-29-2005 Location: NWCT Status: Offline Points: 21145 |
Post Options
Thanks(0)
Quote Reply
Posted: December-09-2008 at 1:13pm |
Im pretty sure thats not the case- Ive never heard of a reverse rotation ZR6 (GM 6.0L). |
|
|
|
|
GaryM
Newbie
Joined: March-13-2008 Location: Chesapeaks Bay Status: Offline Points: 24 |
Post Options
Thanks(0)
Quote Reply
Posted: December-09-2008 at 1:16pm |
|
Well... the starter is not really sealed. The bendix drive needs to extend out of the front of the starter to engage the flywheel so it is subject to water. I have the starter off and apart and beleive me water has found its way inside the armature area as well.
|
|
|
|
|
79nautique
Grand Poobah
Joined: January-27-2004 Location: United States Status: Offline Points: 7872 |
Post Options
Thanks(0)
Quote Reply
Posted: December-09-2008 at 4:04pm |
|
sorry Tim missed that was focusing on Fish nautique and forgot it's a repower.
Gary you need to invest in an automatic bilge because if you are getting that much water into the boat that's not good. But if you need to swap then get a reverse rotation GM starter and go to town got rocket science it's just a start and as long as the flywheel rotates in the same direction that's all that matters. |
|
|
|
|
GaryM
Newbie
Joined: March-13-2008 Location: Chesapeaks Bay Status: Offline Points: 24 |
Post Options
Thanks(0)
Quote Reply
Posted: December-09-2008 at 5:03pm |
|
Already have 2 automatic pumps. The boat would sink without them as everything drains into the bilge. Besides, you would be suprised how low a 6.0 sits as compared to the original Ford power. It does not take all that much water to get to the starter in this configuration.
|
|
|
|
|
8122pbrainard
Grand Poobah
Joined: September-14-2006 Location: Three Lakes Wi. Status: Offline Points: 41045 |
Post Options
Thanks(0)
Quote Reply
Posted: December-09-2008 at 7:36pm |
|
Gary,
Have you tried to see if your starter will physically fit in the other mounting and the bendix lines up with the ring gear? If so, then you would just need the opposite rotation. Probably wouldn't luck out and be that easy!! I'm not sure but can a starter rotation be reversed? A trip to a auto/electric shop may give you a idea! Wondering if it's a different armature or if the polarity is simply reversed in the field or armature. The opposite polarity reverses a industrial DC permanent or shut wound motor! Call up PCM and see if they have a starter for the other location. |
|
|
|
|
GaryM
Newbie
Joined: March-13-2008 Location: Chesapeaks Bay Status: Offline Points: 24 |
Post Options
Thanks(0)
Quote Reply
Posted: December-09-2008 at 8:06pm |
|
The original starter won't work in the upper location. In addition to the wrong rotation the method of attachment is totally different. No way the lower design starter will bolt into the upper location. PCM does not have a starter listed (for the upper location), however, Crusader does list the starter used in the upper location on their 6.0 engines. They also show a different flywheel for the upper location.
I'm about 99% certain these Crusader parts will work on the 6.0 PCM. I was just curious to see if anyone had done this so I could compare part numbers to see if my assumptions are correct. In case anyone is curious the PCM part numbers for the starter and flywheel (lower mount) are RA122019 for the starter and RA138016 for the flywheel. The Crusader part numbers for the upper location starter is RA122009 and the corresponding flywheel is RA138017. The URL's for the PCM parts manual is http://www.pcmengines.com/pdfs/manuals/parts/6.0/L510014.pdf and the URL for the Crusader parts manual is http://www.crusaderengines.com/manuals/L510018.pdf Gary |
|
|
|
|
Beamteam
Newbie
Joined: July-02-2024 Location: Washington Status: Offline Points: 1 |
Post Options
Thanks(0)
Quote Reply
Posted: July-02-2024 at 9:00pm |
|
Gary, fyi, this is not on the starboard side of the motor. It’s the port side, meaning the non drivers side
|
|
|
|
|
Jonny Quest
Grand Poobah
Joined: August-20-2013 Location: Utah--via Texas Status: Offline Points: 2910 |
Post Options
Thanks(0)
Quote Reply
Posted: July-02-2024 at 9:56pm |
|
16 year old thread. Really?
|
|
|
Current
2003 Ski Nautique 206 Limited Previous 2001 Ski Nautique Open Bow 1994 Ski Nautique Open Bow Aqua skiing, ergo sum |
|
|
|
|
GottaSki
Grand Poobah
Joined: April-21-2005 Location: NE CT Status: Offline Points: 3342 |
Post Options
Thanks(0)
Quote Reply
Posted: July-03-2024 at 8:09am |
|
|
|
"There is nothing, absolutely nothing, half so much worthwhile as messing around with boats...simply messing."
River Rat to Mole |
|
|
|
|
